Equipment

Engineer working with a 3D metal printer.

The Center for Manufacturing Support currently has three locations on the JSU campus:

CMS Advanced Manufacturing Hub - Nelson Avenue (Adjacent to Ayers Hall)
63 Nelson Ave, Jacksonville, AL 36265

CMS Additive Innovation Lab - Ayers Hall

CMS Automation Hub - Center for Education & Professional Studies (CEPS) Complex
115 College St SW, Jacksonville, AL 36265

Equipment in the CMS Advanced Manufacturing Hub

· Bescutter Q Series Galvo Fiber Laser Marker

· Bescutter Cube Series Fiber Laser Cutting Machine

· Torchmate 4800 CNC Plasma Table

· World Lasers LR1612 (CO2)

· Boss Lasers HP-3655 (CO2)

· Acer 5VK Knee Mills w/ DRO (2)

· Acer 1740 Lathes w/ DRO and CSS (2)

· Acer Supra 618 II Surface Grinder

· Haas VF2 TSC Vertical Milling Machine

· Haas SL20 CNC Lathe

· Laguna SmartShop SUV CNC Router

· Sodick ALN600G Wire Elecrical Discharge Machine (EDM)

· WARDJet A-1212 Waterjet

· Wilton Horizontal Bandsaw

· Baileigh CS275 Cold Saw

· Drill Presses, Ironworkers, Belt Sanders, Bench Grinders

· Rogue Fabrication M600 Hydraulic Tubing Bender

· Sheet Metal Form Dies and Presses

· Panasonic HM2350 Dip Pulse MIG Welder

· Miller Millermatic 251 MIG Welder

· Esab ES95i TIG Welder

· Media Blasting

· Heat-Treatment

· Stress Relieving

· Wenzel LH 65 CMM

· Virtek LaserQC Scanner

· 3D Measurement Arm

· Mitutoyo AR-20 Hardness Tester

· Mark10 Series 7 Tensile Tester

· Non-Contact Coatings Measurement

· X-Met Portable Mass Spectrometer (X-ray Gun)

· Lost Wax Molding

· Small Part Injection Molding

· Autodesk AutoCAD

· Creo (PRO/Engineer) / Creo Complete Machining Option (CAM)

· Autodesk Fusion 360

· MasterCAM 2019

Material Extrusion: Fused Deposition Modeling (FDM) Technology - Metals

· Markforged Metal X

Available Materials: 17-4 PH Stainless Steel, Copper, Inconel 625, Tool Steels (A2, D2, H13)

Direct Melting Laser Sintering (DMLS) Technology - Metals

· EOS M290

· ORLAS Creator

Available Materials: 316/316L Stainless Steel, 17-4 PH Stainless Steel, Maraging Steel, Copper.

Selective Laser Sintering (SLS) Technology - Polymer

· XYZ MfgPro230 xS (SLS)

· Nexa3D QLS 236 (SLS)

Available Materials: Nylon 12, Nylon 11, TPU

Materials options and availability are subject to change

Equipment in the CMS Additive Innovation Lab

· Markforged Mark 2

· Markforged Onyx PRO

· Markforged X7

· Funmat HT Enhanced (High-temp FDM)

· Fusion 3 F410

· BigRep Studio G2

· Creatbot D600

· Creatbot DX Plus

· Modix Big Meter

Available Materials

· Polymers: PLA, ABS, ASA, TPU, Nylon, Nylon6, High Temp PEEK, among others.

· Composites: Onyx (nylon + chopped carbon fiber), Onyx Flame Retardant, NylonX.

· Continuous fiber reinforcement: Kevlar, Fiber Glass, Carbon fiber.

· Formlabs Form 3L

· Formlabs Form Cell with 6 Form 2 Printers

Available Materials

· Engineering grade resins: tough, flexible, rigid, clear, elastic, biomedical, and others.

Equipment in the CMS Automation Hub

· FANUC LR Mate 200iC

· FANUC LR Mate 200iD

· FANUC CR-7iA Cobot

· FANUC CRX-5iA Cobot

· FANUC M-20iA

· FANUC M-1ia

· Universal Robot (UR) 5

· Universal Robot (UR) 10

· DOBOT Nova 5

· DOBOT CR5

· DOBOT CR10

· Vectis Cobot Welding Stations

· HIWIN RA605

· KUKA KR6 R900 SIXX

· Rethink Robotics Baxter Cobot

· AGV - ROEQ TML200

· Cognex cameras

· FANUC – HandlingTool Operations and Programming

· FANUC – iRVision 2D

· Universal Robot (UR) – Core Training

More training coming soon!

Contact Matthew Rosser, Director of the Center for Manufacturing Support, to book training.
